Capture Rate

100% (For fixed vehicle)

Recognition Time

≤ 200ms (Average)

Recognition Distance

2-10meters (Recommend distance is 3.5-4m)

Adaptable Speed of Car

≤15km/ h

Output Information

License plate number, License plate picture, Access time, Card number

Supported Regions

Thailand, Argentina, Mexico, Chile, Colombia, Turkey, Saudi Arabia, South Africa, Brazil, Peru, Mongolia, Malaysia, Indonesia, Vietnam, UAE, Oman, Egypt, EU, Korea, Pakistan.etc

Working Voltage (V)

220V

Packaging Size

1140mm * 500mm * 310mm

CPU

A7@600 MHz, 32 KBI-cache/ 32 KBD-cache

Flash

NOR FLASH 32M

RAM

DDR3, 256M

Image Sensor

1/2.8”CMOS

Lens

2MP, 3.2mm -11.1mm, Auto focus

Resolutions

1920 × 1080P

Minimum Illuminance

0.1Lux (Standard)

Video Compression Standard

H264

Double Code Stream

Main Stream 1920 * 1080, 1280 * 720 (Optional), 1-25frames/s (25 default)
Substream 704 * 576, 640 * 480, 320 * 240 (Optional),1-25 frames/s (25 default)

Communication

TCP/ IP (10/100Mbps)

I/O Interface

Two relay, Two RS485 outputs, Audio in / out, Barrier status input, Wiegand in & out

Storage

TF Card (Default 8G, Max support 32G)

Reset

Reset

Working Mode

Video trigger

Protection Level

IP65

Operating Temperature

-20°C - +55°C

Dimensions

580mm * 242mm * 220mm
