Parameters

• Model Name

  SBT2000S
  SBT2011S
  SBT2011S

• Reader

  SBT2000S: N/A
  SBT2011S: RFID
  SBT2022S: RFID & Fingerprint

• Controller

  SBT2000S: N/A
  SBT2011S: PGIC controller
  SBT2022S: PGIC controller

• Card Capacity

  SBT2000S: N/A
  SBT2011S: 10,000
  SBT2022S: 10,000

• Fingerprint Capacity

  SBT2000S: N/A
  SBT2011S: N/A
  SBT2022S: 3,000

• Log Capacity

  SBT2000S: N/A
  SBT2011S: 100,000
  SBT2022S: 100,000

• Power Requirements

  AC 110V/220V, 50/60Hz

• Lane Width (mm)

  800 (optional ≤920mm）

• Infrared Sensor

  A sensor

• LED Indicator

  Support

• Cabinet Material

  Cold rolled sheet (optional: SUS304 stainless steel）

• Lid Material

  Acrylic

• Barrier Material

  Tempered glass (optional: stainless steel or acrylic)

• Barrier Movement

  Swing

• Emergency Mode

  Support

• Working Temperature

  -15°C to 60°C

• Working Humidity

  20% to 93% (non-condensing)

• Working Environment

  Indoor / Outdoor (if sheltered)

• Dimension (L*W*H)

  202 * 187 * 1109 ( mm )

• Dimension with Packing (L*W*H)

  280 * 280 * 1160 ( mm )

• Weight (kg)

  24 kg

• Weight with Packing (kg)

  41 kg

• MCBF

  5million

• Warranty

  1 year
