Authentication Method

Face/ Fingerprint/ Card/
Password (Virtual Keypad)

Face/ Scramble QR Code/ Card/
Password (Virtual Keypad)

Certifications

ISO14001, ISO9001, CE, FCC, RoHS

Communication

TCP/IP*1
Wi-Fi (IEEE802.1a/b/g/n/ac) @ 2.4 GHz / 5G GHz
Bluetooth: BLE5.0
Wiegand (Input & Output)*1
RS485: ZKTeco RS48*1
USB: Type A (USB Drive Only)*1
Aux Inputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm output*1, Wired Doorbell*1

Dimension

183 mm*88 mm*20.5 mm (L*W*H)

Display

4"@ TFT Color Touch LED Screen (480*800)

Face Template

3,000 (1:N) (Standard) / 6,000 (1:N)
(Optional)

ID Card Capacity

3,000 (1:N) (Standard) / 10,000(1:N)
(Optional)

Operation System

Linux

Optional Features

Wi-Fi, SRB, WorkCode, Video Door Phone, SIP Clinet

Power Supply

DC 12V 3A (Optional)

Standard Features

ADMS, DST, 14-digit User ID, T9 Keyboard (Input), Photo Capature, Event Photo Capature, Record Query,
Tamper Switch Alarm, Automatic Status Switch, Multiple
Verification Methods, Anti-Passback, Wired doorbell, Schedule Bell, HTTPs / SSH Backend Access, AC
Push and TA Pusch Protocol Switch

Supported Software

Software: ZKBio CVSecurity
Mobile App.: ZKBio Zlink /
Zsmart Cloud Service: ZKBio Zlink
