Preventative Measures

Mask detection / Body temperature detection

Temperature Measurement Distance

50 cm to 120 cm (1.64ft to 3.94ft)

Temperature Measurement Accuracy

±0.3°C (±0.56°F)

Temperature Measurement Range

20°C to 50°C (68°F to 122°F)

User Capacity

50,000

Face Capacity

50,000

Card Capacity

50,000

Transaction Capacity

1,000,000

CPU

64bit Octa-core Customized Computer Vision 1.8GHz CPU

Storage

2GB LPDDR3 / 16GB eMMC

Screen Size

7-inch Touch Screen
720*1280 Pixels

Camera

2MP Binocular Camera

Communication

TCP/IP, USB Host, RS485*, Wiegand Input, Wiegand Output, Wi-Fi, Bluetooth, 4G(optional)
WLAN: 2.4G, 802.11 b / g / n
Bluetooth: BT2.1+EDR / 3.0/4.1 LE / 4.2 BLE
LTE FDD: B1 / B2 / B3 / B4 / B5 / B7 / B8 / B20 / B28
LTE TDD: B38 / B39 / B40 / B41
WCDMA: B1 / B2 / B4 / B5 / B8
GSM: 1800 / 1900MHz

Access Control Interface

RS485 (OSDP v2.1.7), Wiegand In / Out, Lock Relay Output, Exit Button, Alarm Output, Auxiliary Input, Door Sensor, External Bell

Card

125kHz ID card & 13.56MHz IC card
Multi-tech Card Module(optional)

QR Code Scanner

Dynamic QR codes on the ZKBioSecurity mobile application
QR code, PDF417, Data Matrix, MicroPDF417, Aztec scanning in third-party development projects

Fingerprint

Z-ID Fingerprint Sensor (optional)
30,000 Fingerprints

Algorithms

ZKFace 5.6
ZKFinger 10.0

Operating Temperature

-20°C to 55°C (-4°F to 131°F)

Operating Humidity

< 90%RH

Storage Temperature

-25°C to 65°C (-13°F to 149°F)

Storage Humidity

< 90%

Dimension

319.5 mm * 120 mm * 51 mm (12.58 in*4.72 in*2 in) (H*L*D)

Facial Recognition Speed

≤ 0.5s

Facial Recognition Distance

0.5 m to 3 m

Power Supply

DC 12V, 3A
IEEE 802.3af / at

Standard Firmware Functions

Push, Schedule Bell, Automatic Status Switch, Record Query, Access Levels, Groups, Holidays, DST, Duress Mode (Password & Fingerprint), Anti-Passback, Customization of Wallpaper & Screen Saver

Software

ZKBio Time (Only Time & Attendance Firmware)
ZKBio CVSecurity

Certifications

CE, FCC, ISO9001, ISO14001, ISO20000
