Face Capacity

30,000 (Standard), 50,000 (Optional)

User Capacity

50,000

Transaction Capacity

1,000,000

User Photo Capacity

20,000

Event Photo Capacity

10,000

Compatibility

Security Relay Box / Wiegand / RS485 / RS232 Slave Reader With FP / RFID / Barcode (optional) / ZKBioSecurity Software

Standard Functions

Access Levels, Groups, Holidays, DST, Duress Mode, Anti-Passback, Record Query, Custom Wallpaper & Screen Saver, Tamper Switch Alarm

Access Control Interface

Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensor

Preventative Measures

Mask Detection
Body Temperature Detection
Temperature Measurement Accuracy: ±0.3°C (±0.54°F)
Temperature Measurement Range: 20°C to 50°C (68°F to 122°F)

Special Functions

0.3s High Speed Facial Recognition / Alive Body Detection / HTTPS Encryption (optional) / Event Snapshot

Hardware

900MHz Dual Core Customized CPU / 512MB RAM / 8G Flash / 125kHz EM Reader / 13.56MHz IC (optional) / 2MP WDR Low Light Camera / Hi-Fi Audio / Microwave Distance Detection Sensor / 8" High Brightness IPS Touch LCD / Reset Button & Tamper Switch

Communication

TCP / IP

Power Supply

12V DC

Current Draw

< 2,000mA

Algorithm

ZKLiveFace 5.8

Working Temperature

16°C to 35°C (60.8°F to 95°F)

Working Humidity

≤ 93%

Storage Temperature

-40°C to 65°C (-40°F to 149°F)

Storage Humidity

≤93%

Net Weight

Elite Access[TI]'s Net Weight: 1.42kg
Elite Pass[TI]'s Net Weight: 1.83kg

Gross Weight

Elite Access[TI]'s Gross Weight: 2.5kg to 15kg
Elite Pass[TI]'s Gross Weight: 2.96kg to 18.21kg

Dimension

Elite Access[TI]: 144mm * 296.4mm * 28.7mm
Elite Pass[TI]: 144mm * 296.4mm * 25.5mm
