Display

7-inch touch screen

Face Capacity

10,000 (Standard), 20,000 (Optional)

Transaction Capacity

200,000

Temperature Measurement Response Time

≤100ms

Temperature Measurement Distance

30cm to 120cm (0.98ft to 3.94ft)

Temperature Measurement Range

20°C to 50°C (68°F to 122°F)
(Best performance: 28°C to 42°C or 82.4°F to 107.6°F)

Temperature Measurement Accuracy

±0.3°C (±0.54°F), tested in a distance of 80cm (2.63ft)
under 25°C (77°F) environment

Operation System

Linux

Standard Functions

ADMS, T9 Input, DST, Camera, 9-digit User ID, Access Levels, Groups, Holidays,
Anti-passback, Record Query, Tamper Switch Alarm, Multiple Verification Methods

Hardware

Quad-core ARM Cortex-A7@ 1.2GHz, 1GB RAM / 8GB Flash,
2MP WDR Low Light Camera, Adjustable Light Brightness LED

Communication

TCP/IP, Wiegand Input / Output, Wi-Fi, RS485 / RS232

Access Control Interface

3rd Party Electric Lock, Door Sensor, Exit Button, Alarm output, Auxiliary Input

AC Adapter

DC 12V 3A

Operating Temperature

16°C to 35°C (60.8°F to 95°F)

Dimension

120 * 266.5 * 27.7mm

Software

ZKBio Access IVS
