Face Capacity

30,000 (1:N), 50,000 (Optional)

Palm Capacity

5,000 (1:N) (Customized)

User Capacity

50,000

Transaction Capacity

1,000,000, 2,000,000 (Optional)

User Photo Capacity

10,000

Event Photo Capacity

10,000

Compatibility

Security Relay Box Wiegand / RS485 Slave Reader with FP / RFID / Barcode / QR-code ZKBioSecurity Software

Hardware

900MHz Dual Core Customized / Computer vision CPU / 512MB RAM / 8G Flash / 8" Hight light (400lux) IPS Touch LCD / 2MP WDR Low Light Camera / Adjustable Light brightness LED / Hi-Fi Voice / High Sensitivity Microphone / Distance Detection Sensor / Reset Button and Tamper Switch

Access Control Interface

Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensor

Special Functions

0.3s Hight Speed Facial Verification / Liveness Detection / HTTPS Communication Encryption (Optional) / Event Snapshot

Standard Functions

Access Levels, Groups, Holidays, DST, Duress Mode (Password), Anti-Passback, Record Query, Tamper Switch Alarm, Custom Wallpaper & Screen Saver

Preventative Measures

Mask detection
Body temperature detection
Temperature Measurement Distance: 30cm ~ 50cm (1ft ~ 1.64ft)
Temperature Measurement Accuracy: ±0.3°C
Temperature Measurement Range: 34°C ~ 45°C

Communication

TCP/IP / Wiegand Input / Output / Wi-Fi (Optional) / RS485 / RS232*

Algorithm

ZKLiveFace5.8

Palm

FAR ≤0.01%; FRR ≤1% (Customized)

Operating Temperature

16°C ~ 32°C (60.8°F ~ 89.6°F)

Operating Humidity

≤ 93%

Storage Temperature

-40°C ~ 65°C (-40°F ~ 149°F)

Storage Humidity

≤ 93%

Net Weight

853g

Dimension

227 * 143 * 26.1mm (H*L*D)

Power Supply

12V DC

Current Draw

< 2,000mA
