Model Name

ZKBio710
ZKBio730
ZKBio750

Printing method

ZKBio710 : Intel® Celeron® J1900 @ 1.99GHz Optional: Intel ®Celeron® J6412 @ 2.00GHz
ZKBio730 : Intel ®Core ®i3-6100U @ 2.40GHz
ZKBio750 : Intel® Core® i5-6200U @ 2.30GHz

Memory

4GB RAM Standard, DDR3 & DDR4, Up to 8GB
64GB SSD Standard, Up to 512GB
Optional: External Memory Slots (M.2 SATA SSD 120GB & HDD 500GB )

Display

Configuration 1: Main: 15" HD, 1024*768, Capacitive Touch Screen; Second: LED (8C digital tube)
Configuration 2: Main: 15" HD, 1024*768, Capacitive Touch Screen; Second: VFD (2*20 lines)
Configuration 3: Main: 15" HD, 1024*768, Capacitive Touch Screen; Second: 9.7" LCD HD, 1024*768
Configuration 4: Main: 15" HD, 1024*768, Capacitive Touch Screen; Second: 15" LCD HD, 1024*768

Material

Aluminum alloys, ABS

Colour

Black and Gray, White (Optional)

Operating System

Support Windows 7, 8, 10, 11

Dimension

346*190*402mm

Packing Dimensions

405*300*450mm

Net Weight

Configuration 1&2: 5.4Kg
Configuration 3: 6.3Kg
Configuration 4: 7.8Kg

Gross Weight

Configuration 1&2: 7Kg
Configuration 3: 7.9Kg
Configuration 4: 9.3Kg

Interfaces

ZKBio710 ：1* USB 3.0 / 5* USB 2.0 / 1* RJ45 LAN port / 1* COM port / 1* VGA port / 1* Audio jack / 1* MIC IN / 1* Power port

ZKBio730：4* USB 3.0 / 2* USB 2.0 / 2* COM port / 1* VGA port / 1* HDMI port / 1* RJ45 LAN port / 1* Audio jack / 1* MIC IN / 1* Power port

ZKBio750 : 4* USB 3.0 / 2* USB 2.0 / 2* COM port / 1* VGA port / 1* HDMI port / 1* RJ45 LAN port / 1* Audio jack / 1* MIC IN / 1* Power port

Power Supply

DC12V/5A

WiFi

Single-band 2.4GHz (Optional)
Dual-band 2.4GHz/5GHz (Optional)

Bluetooth

Not Support

Options & Peripherals

Built-in fingerprint module
Built-in 2D barcode scanning module
Built-in MSR reader
Built-in RFID reader

Operating Temperature

0°C ~ 40°C at 20% ~ 80% Humidity

Storage Temperature

-15°C ~ 60°C at 20% ~ 80% Humidity

Certifications

ISO9001, CE, FCC, RoHS
