Model Name

ZKBio810
ZKBio830
ZKBio850

CPU

ZKBio810：Intel Celeron J1900 @ 1.99GHz
ZKBio830：Intel Core i3-4030U @ 1.70GHz
ZKBio850：Intel Core i5-4210U @ 1.70GHz

Processor

ZKBio810 : Intel® Celeron® J1900 Quad-Core Processor (2.0 GHz)
ZKBio830 : Intel® Core™ i3-4005U Pro-cessor(1.7GHz) Intel® Core™ i3-4010U Pro-cessor(1.7GHz)
ZKBio850 : Intel® Core™ i5-4200U Processor (1.6 GHz up to 2.6 GHz) Intel® Core™ i5-4210U Processor (1.7 GHz up to 2.7 GHz)

System Memory

2GB Standard, DDR3L 1666MHz (Max.8GB)

Storage Device

32GB Msata SSD Standard,1*2.5’’ HDD / 2.5’’ SSD

OS Supported

Windows 7,Windows 8, Windows 10 IoT Enterprise, POS Ready 7,Linux

Audio

Realtek ALC662

Types

15” TFT LCD, LED Backlight

Resolution

1024*768

Touch Screen

Projected Capacitive

Customer Display

LED 8C digital tube

VGA

1*DB-15

USB

ZKBio810：5*USB 2.0 & 1*USB3.0
ZKBio830：2*USB2.0 & 4*USB3.0
ZKBio850：2*USB2.0&4*USB3.0

COM

ZKBio810：3
ZKBio830：3
ZKBio850：3

LAN

1

Audio

1*Line-out

Cash Drawer

1
0
0

HDMI

1

Operating Temperature

0℃ ~ 35℃ at 20%-80% Humidity

Storage Temperature

- 20℃ ~ 55℃ at 20%-80% Humidity

Dimensions (L*W*H)

347*372*402mm

Packing Dimensions

450*420*480mm

Net Weight

6.10kg

Packing Weight

8.21kg

Power Supply

Adaptor 12V DC 5A

Certifications

CE, FCC

Second Display

10”TFT LCD

Customer Display (VFD)

VFD(2*20 lines)

MSR

3 Tracks

Fingerprint Reader

Built-in fingerprint reader

Power Supply

CE FCC
