Parameters

• Model

  Z8508NEQ

• SYSTEM

• Main Processor

  Multi-core embedded processor

• Operating System

  Embedded LINUX

• VIDEO AND AUDIO

• Max IPC Input

  8CH

• Two-way Talk

  Support

• Audio Compression

  G.711u

• LIVE VIEW

• Display Split

  1 / 4 / 6 / 8 CH

• Resolution

  5MP(2592*1944) / 2MP(1920*1080) / 1.3MP(1280*1024) / 1MP(1280*720) / D1(1024*768)

• Live View Capability

  1CH@5MP / 8CH@D1 (25 / 30fps)

• RECORDING

• Video Compression

  H.265 / H.264

• Recording Resolution

  5MP / 3MP / 1080P / 960P / 720P / D1 / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF

• Max. Decoding Capability

  8CH@5MP(25 / 30fps)

• Incoming Bandwidth

  60 Mbps

• Bit Rate

  Main Stream: 16Kbps ~ 8192Kbps
  Sub Stream: 50Kbps ~ 700Kbps

• Record Mode

  Schedule, Manual, Motion Detection, IVA Events Alarm

• Record Interval

  1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

• PLAYBACK AND BACKUP

• Playback Channel

  4-channel real-time playback synchronously

• Search Mode

  Time / Date, Alarm Types, IVA Search

• Playback Function

  Play, Stop, Play Forward, Play Backward, 30 Seconds Forward, 30 Seconds Backward, Fast Play, Slow Play, Single Frame Play, Hide / ShowTime Bar, Backup, Snapshot, Full Screen

• Backup Mode

  USB Device / Network Remote

• IVA ALARM

• Local IVA Functions

  Tripwire / Target Counting / Counting Statistics / Object Left / Lost / Intrusion

• Regular Detection

  Motion Detection / Video Shelter / Video Loss

• AI Search

  Support search target video by multiple intelligent conditions

• NETWORK

• Network Protocol

  TCP / IP, UDP, HTTP, DDNS, SMTP(SSL), DHCP, RTSP, NTP, P2P

• Max. Online Users

  20

• Web Browser

  Internet Explorer / Microsoft Edge

• ANR

  Support (Automatic Network Replenishment)

• Operation System

  Windows

• Management Platform

  AntarVis 2.0

• Mobile Application

  AntarView Pro+ (iOS & Android)

• P2P Cloud Service

  Support

• Interoperability

  ONVIF Profile S, SDK, CGI, API

• STORAGE & AUXILIARY INTERFACE

• SATA Ports

  1 SATA Port, up to 12TB capacity

• eSATA

  N/A

• Raid 0 /1 / 5 / 6 / 10

  N/A

• HDMI

  1*HDMI (1080P)

• VGA

  1920*1080 / 60Hz, 1280*1024 / 60Hz

• Network Interface

  1 RJ-45 Port (10 / 100Mbps)

• PoE Ports

  N/A

• USB

  3*USB 2.0

• Audio Input/Output

  0 / 1 output

• Alarm Input/Output

  N/A

• RS-485

  N/A

• POWER

• Power Supply

  DC 12V / 2A

• Power Consumption

  24W (without HDD)

• GENERAL

• Casing

  1U

• Operating Temperature

  -10°C to 55°C / 14°F to 131°F

• Operating Humidity

  0% to 90% RH (Non-condensing)

• Dimensions (L*W*H)

  255 * 210 * 43 mm

• Net Weight

  2.5 kg (without HDD)

• Gross Weight

  3 kg (without HDD)
